LEDVANCE AREASTER Multi-Watt LED Flood Light: 200W/150W/100W, 30,000lm, IP66
The powerful LEDVANCE AREASTER Flood Light (LAL200MW) offers selectable output of 200W, 150W, or 100W, delivering up to 30,000 lumens of bright 5000K Daylight. Built for demanding areas, it boasts a heavy-duty IP66/IK08 rating and a 5-year commercial warranty.
Old price: $605.00 incl tax
$500.00 incl tax
LEDVANCE AREASTER LAL200MW: Versatile High-Power LED Flood Lighting
The LEDVANCE AREASTER LAL200MW Multi-Watt Area Light is a premium, professional-grade solution designed to replace traditional high-wattage discharge lighting. This powerful fixture eliminates the guesswork of stocking multiple units by incorporating a simple, built-in switch that allows the installer to select the optimum power consumption and light output: 200W (30,000 lm), 150W (22,500 lm), or 100W (15,000 lm). This superior flexibility ensures you meet precise lighting codes while maximizing energy savings.
Product benefits
- Bright, robust and durable
- Highly versatile due to selectable power steps (Multi Lumen) on the housing
- Flexible mounting options
- 5 years guarantee
Areas of application
- Industrial lighting (e.g. manufacturing plants, logistic centers, warehouses)
- Streets, residential areas, pedestrian zones, parks
- Parking lots, city squares, parks
- Driveways
Product features
- Multi Power and Multi lumen, power selectable
- Luminous efficacy: up to 150 lm/W
- Type III Asymmetric light distribution for area lighting
- Mounting accessories must be ordered separately: Slip Fitter, U-Bracket
- Robust die-cast aluminum housing
- Flicker free
- Photocell detector available for daylight detection
Electrical data
- Nominal wattage 200 W / 150 W / 100 W
- Nominal voltage 100…277 V
- Mains frequency 50…60 Hz
- Nominal current 1660.000 mA
- Inrush current time Th50 300 µs
- Max. number of luminaires per miniature circuit breaker C16 13
- Power factor λ > 0.90
- Total harmonic distortion < 15 %
- Protection class I
- Surge capability (L-N) > 6 kV
- Operating mode Integrated LED driver
Photometrical data
- Luminous flux 30000 lm / 22500 lm / 15000 lm
- Luminous efficacy 150 lm/W
- Color temperature 5000 K
- Light color (designation) Cool White
- Color rendering index Ra 70
- Standard deviation of color matching < 4 sdcm
- Photobiological safety group acc. to EN62778 RG1
Dimensions & Weight
- Length 461.00 mm
- Height 55.00 mm
- Width 287.00 mm
- Product weight 4200.00 g
- Cable length 1000 mm
Materials & Colors
- Product color Black
- Housing color Black
- Body material Aluminum
- Cover material Polycarbonate (PC)
- Light emitting surface material Polycarbonate (PC)
- Glow Wire Test according to IEC 60695-2-12 650 °C
Application & Mounting
- Temperature range at storage -30…+80 °C
- Type of connection Cable, 3-pole
- Type of protection IP66
- Protection class IK (shock resistance) IK08
- Dimmable No
- Mounting type Surface
- Mounting location All surfaces
- Replaceable light source No
Lifespan
- Lifespan L70/B50 at 25 °C > 100000 h 1)
- Lifespan L80/B10 at 25 °C 100000 h 1)
- Lifespan L90/B10 at 25 °C 50000 h
- Number of switching cycles 100000
Control gear
Certificates & Standards
- Standards CB, RCM, TM21, LM79, ISTMT
- Replaceable light source (EPREL) Not replaceable
